Implementation
Overview
The Quantum Proximity Gateway (QPG) is made up of five core components, each of which serves an incredible important and specific role in creating a secure and accessible system. The project was split into these individual submodules in order to improve the modularity of the system, enable parallel development, and also ensure that each component could be tested and deployed individually. Additionally, due to the complexity of the system and the variety of hardware being used, it was important to ensure that each component could be easily replaced or upgraded without affecting the rest of the system.
As a result of this modularity, each component of the QPG project has different technologies and languages that are best suited for their relevant tasks, and so, we will discuss the implementations and the tools and dependencies used for each submodule separately in the following sections.
Registration Site
This website is where the user first interacts with QPG - it allows them to register their ESP32 device with their account, as well as setup the facial recognition that is extremely important for the system to work.
Tools & Dependencies
Next.js
The full-stack React framework which is powering the registration site.
Chakra UI
A modular, accessible component library for a responsive website.
Web Serial API
Enables secure, browser-based communication with the ESP32 over a serial connection.
Web Serial API (ESP32 Communication)
The Web Serial API is what allows the browser to communicate with the ESP32 device over a serial connection. This is what we use to retrieve the MAC address of the ESP32 device, and then send it to the server for registration. In general, users grant permission to access serial devices, which then connects the ESP32 to the browser, allowing data to be sent back and forth between the microcontroller and the webpage.
In registration-site/src/app/page.tsx, we have a connectSerial() function. This function is what is called when the user decides to click on the "Connect to device" button on the main page of the registration website, and it uses the Web Serial API to connect to the ESP32 device. The code is shown below.
async function connectSerial(secret: string): Promise<[string, number]> { // Connect to ESP32 (cu.wchuusbserial)
const log = document.getElementById('target');
try {
// prompt the user to select which serial port they want to connect to
const port = await navigator.serial.requestPort();
await port.open({ baudRate: 9600 });
// setup the writeable stream to the ESP32
const textEncoder = new TextEncoderStream();
const writableStreamClosed = textEncoder.readable.pipeTo(port.writable);
const writer = textEncoder.writable.getWriter();
// setup the read stream from the ESP32
const decoder = new TextDecoderStream(); // Decodes incoming data from ESP32
port.readable.pipeTo(decoder.writable);
const reader = decoder.readable.getReader();
let macAddress = "";
let current_time = 0;
while (true) {
const { value, done } = await reader.read();
if (value) {
if (value.length == 19) { // MAC Address are 17 characters long + 2 newlines
macAddress = value;
reader.releaseLock();
current_time = Date.now();
await writer.write(secret + '\n'); // write the secret key to the ESP32
writer.releaseLock();
break;
}
}
if (done) {
reader.releaseLock();
break;
}
}
return [macAddress, current_time];
}
}
After opening the popup for the user to select a serial port, the function opens the port with a specific baud rate of 9600 (which is what we flashed the ESP32 with). We then set up a text encoder/decoder so that we can actually communicate over the serial lines. Data that is being sent from the browser to the ESP32 uses the writer, while the data getting sent from the ESP32 is received by reading from the reader object.
The function then enters a loop where it waits for a MAC address string to be sent from the ESP32 (we will cover how the ESP32 is sending this MAC address in the ESP32 section). We know that a MAC address is a fixed length (of 17 characters + 2 characters of \r and \n), so we explicitly check for a value of that length. Finally, only once the MAC address arrives do we release the lock we set on the reader and writer and send the newly generated TOTP secret key back to the ESP32.
TOTP Secret Generation
In the same registration-site/src/app/page.tsx file, we have a handleConnect() method in which we generate the shared TOTP secret of size 160 bits (20 bytes), and give it to the ESP32 over the serial connection after storing it in our React state. In the server, this secret is stored with the device so that the user can authenticate using TOTP.
randomBytes(20,(err, buf) => {
const secret = base32Encode(buf, 'RFC4648');
setSecret(secret);
connectSerial(secret).then((result) => {
// rest of the code
});
})
Data Encryption
Before we send any data from the website to the server, we use a post-quantum key exchange library (mlkem) to generate a shared secret with the server, which is then used for AES-GCM encryption on all communications that happen afterwards. This is the code that is contained within registration-site/src/app/EncryptionClient.tsx.
Post-Quantum Key Exchange
In order to do the key exchange, we first start with requesting the server's public key via the server endpoint /kem/initiate. We then encapsulate a shared secret using that public key, and send the ciphertext we generate with that public key encapsulation back to the server, using the endpoint /kem/complete. The server is then able to decapsulate the ciphertext using its private key in order to get the original shared secret key that was generated by the handleConnect() method above. After the endpoint sends the correct response back, we then store the shared secret so that it can be used to symmetrically encrypt all messages going forward. The relevant code snippets for this post-quantum key exchange are highlighted below. These snippets are located in the method genClientSecret().
// retrieve server's public key
await axios.post(`${API_URL}/kem/initiate`, data)
.then(response => {
const public_key_b64 = response.data.public_key_b64;
pk = this.base64ToUint8Array(public_key_b64);
});
// generate the shared secret using mlkem
const sender = new MlKem512();
const [ciphertext, shared_secret] = await sender.encap(pk);
// convert ciphertext to base64 and send to server
const ciphertext_b64 = this.uint8ArrayToBase64(ciphertext);
const complete_data = { client_id: String(this.CLIENT_ID), ciphertext_b64 };
await axios.post(`${API_URL}/kem/complete`, complete_data);
AES-GCM Encryption/Decryption
After the post-quantum handshake, the client now also has a shared secret. We then use the following methods to encrypt and decrypt data according to the AES-GCM standard.
encryptData(data: string): EncryptedData {
const key = this.SHARED_SECRET;
const nonce = randomBytes(24);
const bytes = utf8ToBytes(data);
const aes = gcm(key, nonce);
const ciphertext = aes.encrypt(bytes);
return {
ciphertext_b64: this.uint8ArrayToBase64(ciphertext),
nonce_b64: this.uint8ArrayToBase64(nonce),
client_id: this.CLIENT_ID
}
}
decryptData(data: EncryptedData): string {
const key = this.SHARED_SECRET;
const nonce = this.base64ToUint8Array(data.nonce_b64);
const aes = gcm(key, nonce);
const plaintext = aes.decrypt(this.base64ToUint8Array(data.ciphertext_b64));
return new TextDecoder().decode(plaintext);
}
Encryption essentially takes a JSON string (which will contain username, password, and TOTP secret), and creates a random 24-byte nonce. This nonce serves as a unique one-time-use number that makes sure that every encryption operation we do is distinct, even with the same key being used over many encryptions. In other words, the same (key, nonce) pair is never reused because, if they are, for whatever reason, the they will produce identical keystream blocks, which would reveal the relationship between messages, making it easy for a malicious actor to decrypt.
Decryption, on the other hand, takes a response from the server with almost the same structure (ciphertext, nonce and client id). The function then reconstructs the nonce and ciphertext, and this is then decrypted with AES-GCM, returning the resulting plaintext string which the server originally had.
Registration Flow
function handleRegister() {
// other code
let plaintext = {
mac_address,
username,
password,
secret,
timestamp
}
let data = encryptionClient.encryptData(JSON.stringify(plaintext));
axios.post(`${API_URL}/register`, data).then((res) => {
let decrypted_data: RegisterResponse = JSON.parse(encryptionClient.decryptData(res.data));
// other code
router.push(`/registerFace?mac_address=${mac_address}`);
}).catch((err) => {
// other code
}
To actually send the registration data to the server, we use the handleRegister() method in registration-site/src/app/page.tsx. This method is quite simple, but it is important nonetheless. First off, assuming we have all the information we need (username, password, mac_address, and shared secret key), we create a plaintext object with this information which we later convert into a JSON. Then, we use our encryption client to encrypt the data, as defined above. Finally, we post the data to the server at /register and handle the response accordingly. Once this is done, we need to navigate to the face registration page, which we use our router for, with the argument of the mac address.
Facial Recognition Video Capture
To register the user's face, as aforementioned, they are automatically directed to the registration-site/src/app/registerFace/page.tsx page. The logic for this section is completely encapsulated inside a React component called RegisterFaceContent, and the basic idea is that we first capture a 5-second video using the user's webcam, using a countdown to measure the time and let the user know how much time is remaining. Then, we submit the video the server so that the user's face can be registered.
// request webcam
const stream = await navigator.mediaDevices.getUserMedia({ video: true });
videoRef.current.srcObject = stream; // live preview
const recorder = new MediaRecorder(stream);
const chunks: BlobPart[] = [];
recorder.ondataavailable = (event) => {
chunks.push(event.data);
};
recorder.onstop = () => {
const blob = new Blob(chunks, { type: 'video/webm' }); // record in webm format - most compatible
setVideoBlob(blob);
// Stop the camera
stream.getTracks().forEach(track => track.stop());
};
recorder.start();
We first need to request access to the webcam, which is done via the navigator.mediaDevices.getUserMedia() method. This method returns a promise that resolves to a MediaStream object representing the video stream from the user's webcam, and we then set this stream as the source for our video element, which allows us to preview the video in real-time. After creating a MediaRecorder object (used to record the video stream), we wait for the ondataavailable event, and then push the data into an array of chunks because the data will not be available all at once (due to being a stream). Finally, after the recording ends, we create a new Blob object, because this is the best and most efficient format for sending the video to the server.
The code below shows how we did the 5-second countdown for the video, as well as how we actually submit the video (as a video blob) to the server.
// 5-second video countdown
const countdownInterval = setInterval(() => {
setCountdown(prevCountdown => {
if (prevCountdown <= 1) {
clearInterval(countdownInterval);
stream.getTracks().forEach(track => track.stop());
setRecord(false);
setRecorded(true);
}
return prevCountdown - 1;
});
}, 1000);
// submit video to server as video blob
const formData = new FormData();
formData.append('video', videoBlob, 'recorded-video.webm');
formData.append('mac_address', mac_address as string);
await axios.post(`${API_URL}/register/face`, formData, {
headers: { 'Content-Type': 'multipart/form-data' }
});
Overall, the workflow for the registration site is as follows:
- The user initially visits the main registration page and clicks on "Connect to device".
- The Web Serial API is then used to connect to the ESP32, a newly-generated TOTP secret is sent to the ESP32, and the ESP32's MAC address is transmitted to the browser, which is displayed in that MAC address field.
- The user then fills out their username and password, clicking on the submit button, which calls the server's
/registerendpoint after encrypting the data (AES-GCM with a shared secret generated from a post-quantum handshake). - The server returns a success response, at which point the user is redirected to the face recognition page.
- The user then records a 5-second video with the camera, and the captured video is converted into a video blob and sent to the server, which will then register the user's face (this will be covered in more detail in the Server section).
Throughout the entire process, the EncryptionClient ensures that all sensitive data such as username, password, and TOTP secret, are always encrypted before being sent.
Server
The server is where we handle all of the requests that the other components of the project make, as well as store all of our data. In our case, this means handling how to register an ESP32 device with a user (and their account details), as well as storing a user's accessibility preferences which can be retrieved. The server additionally handles setting up the encrypted communication between QPG devices, ensuring that all data is secure and private, using quantum-secure encryption standards.
Tools & Dependencies
Litestar
Async, fast, and light-weight Python web framework running our server's API.
LibOQS
Open-source library for quantum-safe cryptographic algorithms.
OpenCV
Handles camera input and image preprocessing for facial recognition.
Post-Quantum KEM Key Exchange with LibOQS
The server implements the post-quantum key exchange mentioned above in the Registration Site section by using the LibOQS library (via Python's oqs bindings). This is used to establish the shared secret with the client, and ensure that this secret is safe from potential attacks by classical computers.
def kem_initiate(self, data: KEMInitiateRequest) -> dict:
# create a KEM object from liboqs
server_kem = oqs.KeyEncapsulation(self.KEM_ALGORITHM)
# generate a key pair
public_key = server_kem.generate_keypair()
public_key_b64 = base64.b64encode(public_key).decode()
# store the KEM object in a session dict
self.kem_sessions[data.client_id] = server_kem
return {'public_key_b64': public_key_b64}
def kem_complete(self, data: KEMCompleteRequest) -> dict:
server_kem = self.kem_sessions.pop(data.client_id, None)
if not server_kem:
raise HTTPException(status_code=401, detail='Client not recognised...')
# decode the encapsulated data from client
ciphertext = base64.b64decode(data.ciphertext_b64)
# decapsulate to get the shared secret
shared_secret = server_kem.decap_secret(ciphertext)
# store the shared secret in a dictionary for future use
self.shared_secrets[data.client_id] = shared_secret
server_kem.free()
return {'status': 'success'}
The code above shows how we handle the KEM key exchange on the server side, since we already covered the registration site side previously. The kem_initiate() method, located in server/backend/encryption_helper.py is called when the client first connects to the server, and it generates a public/private key pair using the KEM algorithm specified (ML-KEM-512, in this case). The public key is sent back to the client (registration site), and the KEM object is stored temporarily in a session dictionary until the client returns the encapsulated secret key. Note that we also store the client ID in the session dictionary so that we can identify which client is sending the request.
The kem_complete() method, on the other hand, is called when the client, after encapsulating the plaintext with the public key, send the ciphertext back to the server. For this part of the code, we also use the client ID to identify which client is sending the request, and we retrieve the KEM object from the session dictionary. Then, we remove the client ID from the stored session dictionary since we have already used it. This function then decapsulates the ciphertext from the client using the private key of the KEM object (saved in the temporary session dictionary storage), and retrieves the shared secret. This shared secret is then stored in a dictionary so that it can be used for future communications with the client and data encryption/decryption via AES-GCM. Additionally, we also ensure that we free the KEM object from memory so that we do not use unnecessary resources. The KEM object is no longer required as we have now obtained the shared secret.
Data Encryption with AES-GCM
After the KEM key exchange is complete and the server now has the shared secret, we can use it to encrypt and decrypt using AES-GCM. This code is practically identical to the one in the registration website, just in Python instead of TypeScript, so there is no real need to go into explicit detail about it. The idea is the same - we generate a random nonce, then encrypt the plaintext with the nonce and shared secret key, and finally return the ciphertext and the nonce. For decryption, we do the opposite as before - we take the ciphertext and nonce, and then we decrypt the ciphertext using the nonce and shared key in order to retrieve the original plaintext that was encrypted. This code is all located within server/backend/encryption_helper.py as well.
Handling TOTP
The TOTP (Time-based One-Time Password) is a standard for generating one-time passwords based on a shared secret key and the current time. As we discussed in the registration site section, the TOTP secret is generated when the user registers their device, and it is stored in the database along with the user's account information. The TOTP is then used to authenticate the user when they try to log in to their account by deriving a 6-digit code using a standard TOTP approach. The /devices/credentials endpoint defined in server/backend/app.py is used to first generate the correct TOTP code with generate_totp(). Then, we compare this to the TOTP code passed by the client, and, only if it matches, we return the username and password stored in the database (after decrypting it with the shared secret key). The implementation of these features is shown below.
async def generate_totp(mac_address: str ,transaction: AsyncSession) -> int:
# get secret, timestamp from DB
query = select(Device.secret, Device.totp_timestamp).where(Device.mac_address == mac_address)
result = await transaction.execute(query)
secret, timestamp = result.one_or_none()
return totp(secret, timestamp)
def totp(secret: str, timestamp: int) -> int:
# time-based offset
time_now = time.time()
time_elapsed = int(time_now - timestamp)
TIME_STEP = 30
time_counter = int(time_elapsed / TIME_STEP)
# convert to 8-byte array, run HMAC-SHA1, etc.
# other code
totp_code = bin_code % 10**6 # 6-digit TOTP
return totp_code
For TOTP, the secret is first stored on the device (the ESP32 in this case) and the server. Then, the server calculates the TOTP code based on the current time plus the stored timestamp, which is the time when the TOTP secret was generated. The server then returns this TOTP code to the client, which is then compared to the TOTP code the device sends as a form or second factor authentication.
Facial Recognition
Overview
After the server receives the 5-second video from the registration website, we need to process the video and extract some frames (images) from it in order to retrain the facial recognition model on the new data to identify the person and match their face with the correct username. We will discuss how we do this in the following sections. The general process is outlined in the code below.
video_path = os.path.join(user_video_dir, 'video.webm')
# save the webm
with open(video_path, 'wb') as video_file:
while True:
chunk = await data.video.read(chunk_size)
if not chunk:
break
video_file.write(chunk)
mp4_path = os.path.join(user_video_dir, "video.mp4")
convert_to_mp4(video_path, mp4_path)
extracted_frames = split_frames(mp4_path, user_video_dir)
train_model(extracted_frames, username)
shutil.rmtree(user_video_dir, ignore_errors=True)
The snippet above is the code written for the /register/face endpoint in server/backend/app.py. The general outline is to first take the video blob that we received from the registration website and save it as a file on the server. Then, we convert the video to an MP4 format, and, after this conversion, we split the 5-second video into frames and save them into a local directory we make for the images temporarily. Then, we train the image, and finally delete the images and video so that we do not use unnecessary space on the server or store any personal data.
WebM → MP4 Conversion
The reason we convert the WebM to MP4 is to ensure that all of the data has been received appropriately. When we tried to process the webm video directly, we faced some errors due to the video stream which caused not all of the video data to be received, so this seemed like the best solution. We use ffmpeg, a powerful multimedia framework which is widely used for video and audio processing, in order to do the conversion. The code for this method in server/backend/video_encoding.py is highlighted below, using the subprocess module to call the ffmpeg command line tool.
def convert_to_mp4(webm_path: str, mp4_path: str) -> None:
command = [
'ffmpeg',
'-i', webm_path,
'-c:v', 'libx264',
'-c:a', 'aac',
'-strict', 'experimental',
'-y',
mp4_path
]
subprocess.run(command, check=True, stdout=subprocess.PIPE, stderr=subprocess.PIPE)
Extracting Frames
In order to train the facial recognition model, we need images rather than a video. To do this, we use the split_frames() method in server/backend/video_encoding.py. Originally, this method split the video into 5 frames, but we later realised that this is too small of a dataset to train the model on for a user, since it's not very accurate. Instead, we extract 20 frames at continuous intervals, skipping the first 0.5 seconds of the video to ensure that we wait for the camera to stabilise. As we mentioned before, we use OpenCV to do this, and then we save the frames in a temporary directory that we create for this specific user. This will be deleted after the model is trained, along with the videos (in both webm and mp4 formats).
def split_frames(mp4_path: str, user_video_dir: str):
cap = cv2.VideoCapture(mp4_path)
fps = cap.get(cv2.CAP_PROP_FPS)
total_frames = int(cap.get(cv2.CAP_PROP_FRAME_COUNT))
skip_frames = int(0.5 * fps) # skip half second
interval = max(1, (total_frames - skip_frames) // 21)
for i in range(1, 21):
frame_idx = skip_frames + i * interval
# other code
ret, frame = cap.read()
# other code
cv2.imwrite(frame_path, frame)
Training the Facial Recognition Model
The train_model() method in server/backend/face_recognition.py is where we actually train the model. We use the face_recognition library in order to do this, which is a very powerful and well-known library in Python used for face recognition (as the name implies). The library uses a deep learning model called ResNet-34 to extract facial features from images, and then we use these features to train a simple SVM (Support Vector Machines) classifier and save the 128-dimensional embeddings computed by the model for each person. The model is essentially just a bunch of face embeddings that are stored in a database and mapped to the usernames of a person. After training the model, the next time the facial recognition request is made, we simply load the encodings data and compare the current feed of the Raspberry Pi 5's camera module to the embeddings stored in the database. The code for the training of the model is quite straightforward:
def train_model(frame_paths, username):
# read/create encodings data structure
if os.path.exists("encodings.pickle"):
with open("encodings.pickle", "rb") as f:
data = pickle.loads(f.read())
knownEncodings = data['encodings']
knownNames = data['names']
else:
knownEncodings = []
knownNames = []
# find faces and compute embeddings for each frame
for (i, imagePath) in enumerate(frame_paths):
image = cv2.imread(imagePath)
rgb = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)
boxes = face_recognition.face_locations(rgb, model="hog")
encodings = face_recognition.face_encodings(rgb, boxes)
for encoding in encodings:
knownEncodings.append(encoding)
knownNames.append(username)
# save back to 'encodings.pickle'
data = {"encodings": knownEncodings, "names": knownNames}
with open("encodings.pickle", "wb") as f:
f.write(pickle.dumps(data))
Storing JSON Preferences
Overview
Each user has a set of preferences that they can set in order to control the accessibility of their device. These preferences are stored in a JSON format, as specified in the System Design section. These are stored in a preferences column in the devices table in server/backend/app.py according to sqlalchemy's MutableDict JSON type in order to handle updates to the JSON data.
class Device(Base):
__tablename__ = 'devices'
mac_address = mapped_column(primary_key=True)
# other code
preferences = mapped_column(
MutableDict.as_mutable(JSON),
default=lambda: deepcopy(DEFAULT_PREFS),
nullable=False
)
The reason we use a MutableDict is to ensure that the server can track changes in the dictionary and automatically commit them to the database, rather than having to rely on the developers to do this manually. This is important because the preferences can be updated at any time by the desktop application, and we want to ensure that these changes persist for the next time that the user logs in into a device. The default preferences are defined in server/backend/json_example.json, and we load these automatically when a user's device is registered.
Updating the Preferences
@post('/preferences/update')
async def update_json_preferences(data: EncryptedMessageRequest, transaction: AsyncSession) -> dict:
decrypted_data = encryption_helper.decrypt_msg(data)
validated_data = UpdateJSONPreferencesRequest(**decrypted_data)
query = select(Device).where(Device.username == validated_data.username)
device = (await transaction.execute(query)).scalar_one_or_none()
device.preferences = validated_data.preferences
await transaction.commit()
return encryption_helper.encrypt_msg({'preferences': validated_data.preferences}, data.client_id)
The code shown above is the POST /preferences/update endpoint which handles updating the JSON file (with requests to this being sent from the desktop application). First, as always, we decrypt the data received from the client (the desktop app), and then we validate the data is in the correct format by using our Pydantic-defined models. After validating the data, we query the database to get the device with the specific username (since these will also be unique), and we update the preferences column with the new preferences. The desktop app sends the full JSON back, so we can simply replace the entirety of the preferences column, rather than having to search through the JSON and updating each key-value pair individually, which could potentially be a complex operation. Finally, we encrypt the updated preferences and send them back to the client, so that they can be reflected in the desktop application.
ESP32 Code
This is the code needed on the ESP32 device which ensures that its MAC address is transmitted when necessary, and also handles the Bluetooth Low Energy communication with the Raspberry Pi as the users approaches the computer to be logged in into. It also handles the TOTP secret key generation.
Tools & Dependencies
ArduinoBLE
A light-weight BLE library for Arduino, used to handle the BLE communication.
PlatformIO
An open-source ecosystem, used to manage libraries and dependencies.
Bluetooth Low Energy (BLE) Setup
In ESP32-code/BLE-Broadcasting/src/main.cpp, the code sets up the BLE server using the ESP32's built-in capabilities. The ESP32 acts as a BLE peripheral, broadcasting its MAC address and other information to nearby devices, using the ArduinoBLE library to handle the BLE communication. The ESP32 advertises its MAC address and a custom service UUID, allowing the Raspberry Pi to discover and connect to it.
BLEDevice::init("ESP32 Key"); // Initialize BLE with a device name
BLEServer *pServer = BLEDevice::createServer();
pServer->setCallbacks(new MyServer()); // Custom server callbacks
BLEService *pService = pServer->createService(SERVICE_UUID);
pCharacteristic = pService->createCharacteristic(
CHARACTERISTIC_UUID,
BLECharacteristic::PROPERTY_READ |
BLECharacteristic::PROPERTY_WRITE
);
In the code above, we first initialise the BLE device with a name, and then we create a BLE service and a characteristic. The characteristic is for reading and writing data, and it is set up with the PROPERTY_READ and PROPERTY_WRITE properties, allowing a central device (the Raspberry Pi, in our case) to read/write data from/to it. The UUIDs for the service and characteristic are defined at the top of the file (not shown above), and they are used to identify the service and characteristic when the Raspberry Pi connects to the ESP32.
BLEAdvertisementData oAdvertisementData;
oAdvertisementData.setName("ESP32 Key");
oAdvertisementData.setCompleteServices(BLEUUID(SERVICE_UUID));
BLEAdvertising *pAdvertising = BLEDevice::getAdvertising();
pAdvertising->setAdvertisementData(oAdvertisementData);
pAdvertising->start();
BLEDevice::startAdvertising();
The code above sets up and configures an advertisement packet so that other devices can discover and connect to the ESP32 via BLE. We ensure that the advertisement data includes the device name and the service UUID, which allows the other devices (Raspberry Pi) to identify the ESP32 when scanning for nearby devices. The BLEAdvertising object is used to start advertising the service, and the BLEDevice::startAdvertising() method is called in order to begin broadcasting the packet.
Reading the MAC Address over Serial
By default, each ESP32 device (or any device with a Network Interface Card in general) has a unique MAC address. This is used to identify the device on the network, and it is a 6-byte hexadecimal number. The ESP32 has a built-in function to retrieve the MAC address, which we use to send the MAC address to the Raspberry Pi when it connects to the ESP32 via BLE. In the main loop() function of ESP32-code/BLE-Broadcasting/src/main.cpp, we continually print the MAC address of the device until the device receives a secret key from the Raspberry Pi. The code snippet below shows how we do this.
if (!done) {
BLEAddress address = BLEDevice::getAddress();
Serial.println(address.toString().c_str());
}
Handling the TOTP Secret
Overview
The logic behind this section is to first read the TOTP secret over Serial from the Raspberry Pi, and then generate the TOTP code using the secret key and a local time counter. The TOTP code is then sent back to the Raspberry Pi via BLE by writing it to the BLE characteristic. Once we read the secret string, we set a flag (done, in the code below), which means we no longer need to print the MAC address to the Serial monitor. We also reset the time_now variable to treat this moment as the start time for the TOTP code generation.
if (Serial.available() > 0) {
secret = Serial.readStringUntil('\n');
if (secret.length() > 0) {
done = true;
time_now = 0; // treat this moment as 'epoch'
}
}
Generating TOTP Codes
The TOTP logic is located in ESP32-code/BLE-Broadcasting/src/totp.cpp, and it is quite simple using mbedtls for HMAC-SHA1. Firstly, every second, the time_now variable is incremented by 1, and we use this variable as the number of seconds since the secret was received. Typically, TOTP uses 30-second steps, so, in generate_totp(), we divide time_now by 30 in order to find the time step. This approach ensures that the TOTP code is generated based on the time elapsed since the secret was received, rather than the time when the device was powered on. Additionally, we avoid needing an RTC (Real-Time Clock) or a network timer, which would be impractical for a low-power device like the ESP32.
if (done) {
otp = generate_totp((const unsigned char*)secret.c_str(), secret.length(), time_now);
String otp_str = String(otp);
pCharacteristic->setValue(otp_str.c_str());
}
delay(1000);
time_now += 1;
unsigned int generate_totp(const unsigned char *key, size_t key_len, uint64_t time_now) {
uint64_t time_counter = time_now / TIME_STEP; // TIME_STEP = 30
unsigned char counter[8];
// convert time_counter to an 8-byte array
for (int i = 7; i >= 0; i--) {
counter[i] = time_counter & 0xFF;
time_counter >>= 8;
}
// HMAC-SHA1 on counter
// other code
// truncate the 20-byte HMAC down to a 6-digit TOTP
unsigned int otp = bin_code % 1000000;
return otp;
}
Raspberry Pi Code
This code checks for BLE signals from registered ESP32 devices and verifies their credentials, alongside constantly checking the distance from the computer. Once the distance is small enough, it uses the camera module attached to the Raspberry Pi and checks for the registered user, and if they are found the Raspberry Pi 5 communicates with the Raspberry Pi Pico via UART which acts as a USB HID (Human-Interface Device) keyboard connected to the computer to be logged in into, and types out the user's username and password.
Tools & Dependencies
LibOQS
Open-source library for quantum-safe cryptographic algorithms.
BluePy
A Python library for Bluetooth Low Energy communication on Linux.
Circuit Python
A microcontroller-focused version of Python used on the Pico.
Post-Quantum Encryption
This code is almost the same as that located in the server, and this is also in Python. Therefore, we will not discuss this any further, since the section in the server can be referred to.
BLE Device Scanning
Overview
The Raspberry Pi acts as a central device that scans for nearby BLE-enabled peripherals that match the known MAC addresses which are retrieved from the server. The code uses BluePy to find RSSI (signal strength) and read the TOTP code from the characteristic. The ScanDelegate class located in rpi-code/main/scan.py recieves notifications when a device is discovered and when the RSSI value changes (at certain intervals).
Scanning
The scan_devices() method is what we use in order to scan for nearly BLE peripherals, and it begins by getting a set of all addresses that we are looking for, followed by creating a simple Scanner object. It then starts the scan and waits for a certain amount of time (3 seconds, in this case) to find devices - this is known as passive mode. Then, we stop scanning to check if any of the found devices match any of the devices we are looking for. If we find a device, we check if the RSSI value is above a certain threshold, and if it is, we read the TOTP code from the characteristic. We also make sure to remove devices from the list of devices we found if they have not been updated within a timeout limit. The code below shows how we do this.
def scan_devices():
while True:
addresses = set(get_all_mac_addresses())
data = reload_encoding() # fetch face encodings
scanner = Scanner().withDelegate(ScanDelegate())
try:
scanner.start(passive=True)
scanner.process(timeout=3)
except Exception as e:
logging.error(f"Error during device scanning: {e}")
# continue with the next iteration if scanning fails
sleep(1)
continue
# remove devices that have not been updated within the timeout limit
for dev in list(devices):
if time.time() - devices[dev]['last_seen'] > TIMEOUT_LIMIT:
print(dev, "has disappeared.")
del devices[dev]
within_range_mac_addresses = [
mac for mac in devices if devices[mac].get('distance', float('inf')) <= DISTANCE_LIMIT
]
# face recognition and then UART code
Reading the TOTP Code
When a discovered device's MAC address is in the addresses set (from the code above), the code attempts to connect and then read the TOTP code from the device's BLE characteristic. Assuming the device is in range, device[mac_address]['value'] will now be holding the integer TOTP code te ESP32 produced, and we can use this to verify the user. After storing the integer TOTP code, we then disconnect from the peripheral. The code below shows exactly how this is done.
class ScanDelegate(DefaultDelegate):
def handleDiscovery(self, dev, isNewDev, isNewData):
if dev.addr in addresses:
distance = self.calculateDistance(dev.rssi)
# other code
try:
with Peripheral(mac_address) as peripheral:
# connected now
service = peripheral.getServiceByUUID(SERVICE_UUID)
characteristic = service.getCharacteristics(CHARACTERISTIC_UUID)[0]
value = characteristic.read().decode("utf-8")
devices[mac_address]['value'] = int(value)
peripheral.disconnect()
except Exception as e:
logging.error(f"Error: {e}")
Facial Recognition
# main loop capturing frames
def main_loop(self, list_of_names):
while time.time() - start_time_loop < 2: # Check for 2 seconds
frame = picam2.capture_array()
for name in list_of_names:
processed_frame, person_checking_found = self.process_frame(frame, name)
if person_checking_found:
# found the user
return name
return None
# comparison of encodings
self.face_locations = face_recognition.face_locations(rgb_resized_frame)
self.face_encodings = face_recognition.face_encodings(rgb_resized_frame, self.face_locations, model='large')
for face_encoding in self.face_encodings:
matches = face_recognition.compare_faces(self.known_face_encodings, face_encoding)
# if match, get name from known_face_names
In rpi-code/main/recognise.py, we use the camera module attached to the Raspberry Pi 5 to capture images and perform facial recognition. First, we load a Face Recognition model with the face encodings we retrieved from the server. Then, in an exactly 2-second loop, we capture as many frames as possible frm the Picamera2 (the camera module connected to the Raspberry Pi 5). We then find the encodings of these images and compare them with our known users (retrieved from the server), and finally, if a match is found, we return the user's username, which can then be used to send the appropriate data via UART to the Pico.
UART Connection from Raspberry Pi 5
After verifying TOTP and the face recognition, the Pi 5 gets the username and password of the relevant user from the server. Then, these credentials are sent to the Raspberry Pi Pico via UART, which will act as a USB HID keyboard. The code for this UART connection from the Raspberry Pi 5 side is located in rpi-code/main/uart_rpi5.py and snippets of it are shown below.
def write_to_pico(username, password):
ser = serial.Serial('/dev/ttyAMA0', baudrate=9600, timeout=1)
try:
while True:
json_data = f'{{"username": "{username}", "password": "{password}"}}\n'
ser.write(json_data.encode())
response = ser.readline()
if response:
decoded_response = response.decode('utf-8').strip()
if decoded_response == "OK":
return
time.sleep(1)
finally:
if ser.is_open:
ser.close()
First, the code opens a serial connection to the Pico at 9600 baud. Then, it enters a loop where sends the username and password to the Pico in an encoded JSON format until a valid response (after being correctly decoded) is received from the Pico. If no response is recieved, the Pi 5 will try the same thing again after a 1-second delay.
Raspberry Pi Pico USB HID Emulation
The Pico has a CircuitPython script which handles the UART communication with the Raspberry Pi 5, and then acts as a HID keyboard to type the username and password into the device to be logged in into. First, the Pico listens over UART on the GPIO pins GP0/GP1. Then, after receiving the JSON from the Raspberry Pi (as specified above), the Pico then simulates keyboard input via the Adafruit HID library. Note that the target system recongises the Pico as a standard USB HID keyboard when the Pico connects to it as a peripheral, and this is what allows the Pi to type the user's credentials automatically. The code for this is located in rpi-code/pico/pico-hid.py, and is shown below.
import usb_hid
from adafruit_hid.keyboard import Keyboard
from adafruit_hid.keyboard_layout_us import KeyboardLayoutUS
from adafruit_hid.keycode import Keycode
keyboard = Keyboard(usb_hid.devices)
keyboard_layout = KeyboardLayoutUS(keyboard)
while True:
response = receive_data() # read from UART
if response:
username, password = parse_response(response)
if username and password:
# type out username, press Enter
keyboard_layout.write(username)
keyboard.press(Keycode.ENTER)
keyboard.release_all()
# type out password, press Enter
keyboard_layout.write(password)
keyboard.press(Keycode.ENTER)
keyboard.release_all()
Desktop App
This application opens as soon as a user is logged in and immediately fetches their preferences from the server, executing commands as necessary to have these preferences loaded. This can be things like increasing zoom or high contrast mode, or even opening particular applications on startup. The application also has a chatbot, which the user can talk to, and the chatbot will automatically be able to determine how to create and execute a command so that the user's needs are met (and saved for the next time they login into any device).
Tools & Dependencies
Next.js
The full-stack React framework which is powering the frontend of this app.
Tauri
A light-weight framework for building cross-platform desktop apps.
Ollama-rs
A Rust client for interacting with the Ollama LLM server (running locally).
Tauri Application Setup
The typical pattern for a Tauri application is to have a src-tauri directory, which contains the Tauri configuration and the all of the Rust code for the backend. Additionally, the main.rs doesn't really have a lot of code in it, it's just the minimal entry point for the Tauri application which hands off the control to lib.rs and other files. In the latter file, we do most of our initial setup and anything that needs to be run before the Tauri app starts up is called. Additionally, all the necessary plugins and setup is done here, such as adding the tauri_plugin_shell plugin which allows us to run shell commands from the Tauri app. The general setup for the Tauri app which we use is given below.
if dotenv().is_err() {
from_filename(".env.example").ok();
}
The above code is how we load the environment variables from the .env.example file at the root of the desktop application project (i.e. in desktop-app/QPG-Application/). This is important because we use the variables defined in this file (the ollama URL and the server URL) in the code whenever we need to make a request to the server or the LLM. The idea of the using environment variables is to avoid having to hard-code values, and making it easier for developers to change these.
tauri::Builder::default()
.setup(move |app| {
This is how we actually build the Tauri application, and the setup() method is a closure which initialises the app state and allows us to do an post-start tasks required for certain setups and configurations (such as invoking the encryption handler).
tauri::async_runtime::block_on(async move {
if let Err(err) = commands::startup::init_startup_commands( // startup commands
)
});
let listener_handle = app.app_handle().clone();
listener_handle.listen("frontend-loaded", {
let captured_handle = listener_handle.clone();
move |_event| {
if let Err(err) = commands::startup::init_startup_apps(
)
}
});
The code given above is how we actually call our initial startup commands and applications. The first chunk of code is run as soon as the application opens, calling all the startup commands necessary (which are saved in the server). On the other hand, the second chunk tells the Tauri application that the startup applications should only load when the frontend-loaded message is received from the frontend - something which we emit once the initial animation of the application is complete.
.invoke_handler(tauri::generate_handler![
Finally, the invoke_handler() method is how we actually set up the Tauri application to handle the commands and events that are emitted from the frontend. This is how we call Rust functions from the frontend - exposing these Rust commands to the JavaScript/Next.js (frontend) environment.
Post-Quantum Encryption
As before, this is practically the same encryption code used in the server and the registration site. The only difference is that it is written in Rust and we specifically use the AES-GCM at 256 bits for the encryption (as this was the best balance between efficiency and security for this particular module of the code). For more information on the encryption and how it works, please refer to the server section above.
Preferences JSON
Overview
One of the most important aspects of this desktop application, the preferences JSON is used to store the user's preferences and settings for the application within the server. As soon as the Tauri app is loaded, this is the first thing we retrieve since we need to be able to load the preferences immediately for the user. In this section, we will discuss where the JSON is used, how it is used and updated, as well as how we filter it and why we do this. Note that the JSON is extremely important for the AI agent since we set a system prompt for the LLM, giving the JSON file as context for the LLM to generate/choose commands from.
Fetching the Preferences
The very first thing we need to be able to do is to actually fetch the preferences from the server. This is done in the desktop-app.QPG-Application/src-tauri/src/preferences/mod.rs file, where we have a function called fetch_preferences_impl(), which is what actually defines what to do in order to fetch the preferences. Essentially, this function makes a request to the server to get the preferences for the user, and then it returns the preferences in a format that can be used by the frontend, but it also calls another method to filter the JSON. Additionally, in case of a failed request to the server, we also have a fallback JSON file in the project directory which is read. The code for this is given below.
pub async fn fetch_preferences_impl() -> Result<String, String> {
// other code
let default_commands = match load_default_app_config("src/json_example.json") {
Ok(config) => {
serde_json::to_value(config).unwrap_or(Value::Null)
}
};
let mut url = url::Url::parse(&format!("{}/preferences/{}", SERVER_URL.to_string(), username)).unwrap();
url.query_pairs_mut().append_pair("client_id", &encryption_client.client_id);
let client = Client::new();
let preferences_json = match client.get(url).send().await {
// other code
let flattened = match serde_json::from_str::<Value>(&preferences_json) {
Ok(mut val) => {
if let Value::Object(ref mut root_obj) = val {
if let Some(Value::Object(inner_prefs)) = root_obj.remove("preferences") {
match serde_json::to_string_pretty(&Value::Object(inner_prefs)) {
Ok(s) => s,
// other code
state.update_jsons(&flattened, &filtered_json_str).await;
Ok(filtered_json_str)
}
As we can see above, first we load the fallback JSON in case the request to the server doesn't work. Then, we make the request to the server to get the preferences, encrypting and decrypting as necessary. Then, we parse the JSON to filter it, and finally we update the state of the application with the new JSON so that it can be used everywhere else by the code (even in the frontend), without having to request it again from the server.
Filtering the Preferences
By filtering the JSON in this case, we mean stripping it down so that we only have the commands relevant to the current Operating System. In other words, we get the environment of the current system using Tauri's built-in utilities, and then remove the unnecessary keys from the JSON. This is important because we don't want to have to deal with unnecessary data, and it also means that other information can fit more easily into the LLM's context window.
pub fn filter_json_by_env(json_str: &str, env: &str) -> Result<String, serde_json::Error> {
let mut data: Value = serde_json::from_str(json_str)?;
if let Value::Object(ref mut categories) = data {
for (_key, setting_value) in categories.iter_mut() {
if let Value::Object(ref mut setting_obj) = setting_value {
if let Some(Value::Object(commands)) = setting_obj.get_mut("commands") {
*commands = commands.iter().filter(|(k, _)| k.as_str() == env)
.map(|(k, v)| (k.clone(), v.clone())).collect();
}
}
}
}
serde_json::to_string_pretty(&data)
}
The code above shows how we filter the JSON. It is relatively straightforward, but essentially, we iterate through the JSON and remove any keys that are not relevant to the current environment. The env variable is passed in as a parameter, and it is used to determine which keys to keep in the JSON. This env variable is passed in after being returned from the get_platform_info() method found in desktop-app/QPG-Application/src-tauri/src/state/mod.rs. This method is shown below, and, as aforementioned, uses Tauri's target_os configuration to reliably determine the current environment.
#[tauri::command]
fn get_platform_info() -> String {
#[cfg(target_os = "macos")] { return "macos".into(); }
#[cfg(target_os = "windows")] { return "windows".into(); }
#[cfg(target_os = "linux")] {
let frontend_env = get_linux_gui();
if let Some(env) = frontend_env {
if env.to_lowercase().contains("gnome") { return "gnome".into(); }
else { return format!("linux-{env}").into(); }
} else { return "linux-unknown".into(); }
}
}
We do also differentiate between the different Linux environments, since there are a lot of various GUIs that can be used. However, we are only concerned about the GNOME environment since this is the most popular one, as well as the GUI we are using when testing the app. It is also the environment for which we have already populated the JSON preferences commands with.
Ollama Generation
The Ollama generation is done using the ollama-rs library, which is a Rust client for the Ollama LLM server. This library allows us to easily interact with the Ollama server and generate text using the LLM, and the code for this is relatively straightforward, as underlined below. Our generate_impl() method's implementation, located in desktop-app/QPG-Application/src-tauri/src/commands/generation.rs, is shown below.
pub async fn generate_impl() -> Result<GenerateResult, String> {
let filtered_json = state.get_filtered_json().await;
let mut ollama = g_ollama.0.lock().await;
let mut seen_chats = seen_chats.0.lock().await;
if !seen_chats.contains_key(&request.chat_id) {
seen_chats.insert(request.chat_id.clone(), true);
let sys_prompt = format!(...);
}
let best_match = crate::preferences::find_best_match(&request.prompt, &filtered_json);
let best_match_json = match best_match {
Some(ref key) => {
let parsed_json: Value = serde_json::from_str(&filtered_json).unwrap_or(Value::Null);
if let Value::Object(mut root) = parsed_json {
if let Some(matching_value) = root.remove(key) {
let mut new_obj = serde_json::Map::new();
new_obj.insert(key.clone(), matching_value);
let snippet = serde_json::to_string_pretty(&Value::Object(new_obj))
.unwrap_or_else(|_| filtered_json.clone());
state.set_best_match_json(&snippet).await;
snippet
}
}
}
};
// other code
}
Initially, we set a system prompt for the LLM providing it with context. We tell it that it is supposed to always return a command (for preferences) and a text response (which will be shown to the user). Additionally, we give it the entire JSON (after being filtered for the environment) which it can use to search for commands. The LLM is then asked to find the best match for the command (i.e. the key in the JSON which best matches the user's prompt), and we use this to set the best_match_json variable. This is done using the find_best_match() method, which uses NLP and the cosine similarity algorithm in order to ensure that the model has no hallucinations (or, at least, very few of them). After getting this best match snippet of the JSON, we prepend it to the beginning of the relevant user prompt, which suggests to the LLM that it should use this JSON snippet to generate the command.
NLP Cosine Similarity
Originally, when we just gave the LLM the full JSON, it would often hallucinate and return commands that were not actually in the JSON. This was a problem because we wanted to ensure that the LLM only returned commands that we actually white-listed and wanted it to execute. In order to solve this problem we tried a few different NLP similarity algorithms, and eventually ended up using the cosine similarity as it gave us the lowest rate of hallucinations. The code for how we used the cosine similarity (as defined in the Algorithms section) to find the best match in the JSON is shown below.
fn cosine_similarity(set1: &std::collections::HashSet<String>, set2: &std::collections::HashSet<String>) -> f64 {
let intersection = set1.intersection(set2).count() as f64;
let norm1 = set1.len() as f64;
let norm2 = set2.len() as f64;
if norm1 == 0.0 || norm2 == 0.0 {
return 0.0;
}
intersection / (norm1.sqrt() * norm2.sqrt())
}
Command Execution and Startup Applications
Executing the actual commands is done using the tauri_plugin_shell plugin, as we mentioned before, which allows us to run shell commands from the Tauri app itself. The commands returned from the LLM's responses are run in this way, and is also how we run the startup applications (using some built-in features of Linux Operating Systems). We also ensure that we have a whitelist of commands that we allow the Tauri app to run, otherwise there could be potential security issues.
// preferences command
let command_parts: Vec<&str> = command.split_whitespace().collect();
let (base_parts, value_part) = command_parts.split_at(command_parts.len() - 1);
let last_value = value_part.first().unwrap();
let base_cmd_str = base_parts.join(" ");
let valid_commands = gather_valid_commands_for_env(&state, &platform_info).await?;
let shell = app_handle.shell();
match shell.command(&base_parts[0]).args(&base_parts[1..]).arg(last_value).output().await {
// other code
}
// startup application command
let command_base = command.trim_end_matches(" &").trim().to_string();
let startup_apps = state.get_startup_apps().await;
let bg_app_cmd = format!("nohup {} >/dev/null 2>&1 &", command_base);
let shell = app_handle.shell();
match shell.command("sh").args(["-c", &bg_app_cmd]).output().await {
// other code
}
The general preferences commands are relatively straightforward - we just split the commands by whitespaces and put them into the command() method, args() method (for all arguments in the middle), and arg() method (for the last argument). Alternatively, for the startup applications, we need to do a bit more work - we essentially simulate a sub-shell process and use the nohup bash command, alongside /dev/null 2>&1 &, which allows us to run the command in the background and not have it be a part of the parent process (i.e. the Tauri application). If it was a part of the parent process, then we would need to wait for the startup applications to close before being able to open the Tauri app itself. The code above shows examples of these preferences and startup application commands.
