Project Requirements

Detailed analysis and documentation of the Portalt project requirements

Partner Introduction

IBM is a global technology company with a rich history of innovation spanning over a century. Their Innovation Centre at York Road, Waterloo serves as a hub for showcasing cutting-edge technologies and solutions to clients and partners. The centre demonstrates IBM's latest advancements in areas such as quantum computing, artificial intelligence, cloud solutions, and more.

The Innovation Centre plays a crucial role in IBM's business strategy, allowing potential clients to experience firsthand how IBM's technologies can transform their operations. However, the physical limitations of the centre mean that international clients and partners often face challenges in accessing these demonstrations without traveling to the UK.

Project Background

Currently, IBM faces a significant challenge with their Innovation Centre: international clients cannot experience the centre's offerings without physically traveling to the UK. This limitation restricts IBM's ability to showcase their innovations to a global audience efficiently.

For example, a potential client in the UAE interested in IBM's quantum computing solutions would need to arrange international travel to visit the Innovation Centre in Waterloo. This creates barriers in terms of time, cost, and logistics, potentially impacting business opportunities.

Our project addresses this challenge by creating an augmented reality (AR) application that enables remote visitors to virtually experience the Innovation Centre. This solution will leverage the UBIQ online environment to create an immersive, interactive experience that captures the essence of being physically present at the centre.

The application will allow multiple participants from different locations to simultaneously visit the virtual Innovation Centre, interact with 3D models of IBM's products (such as their quantum computer), and engage with both IBM representatives and an AI-powered chatbot for information.

Additionally, the solution is designed to be adaptable for other contexts, such as NHS environments where medical students could remotely learn about specific organs or procedures with guidance from professors.

Project Goals

Our primary aim is to develop an innovative augmented reality solution that breaks down geographical barriers for IBM's Innovation Centre, enabling global access to their cutting-edge technologies while creating a template that can be adapted for various industries. The project will focus on creating an immersive, interactive experience that closely mimics physical presence while leveraging AI to enhance user interactions.

Immersive Multiplayer Environment

Create an immersive multiplayer AR environment that allows IBM representatives and international clients to interact in real-time as VR avatars, providing remote access to the Innovation Centre's offerings.

Intuitive Admin Interface

Develop an intuitive admin interface for IBM staff to easily upload, position, and manage 3D models of their products in the virtual environment, ensuring content remains consistent for all users.

AI-Powered Interactions

Implement AI-powered interactions through a RAG-enabled chatbot with voice responses and Granite as an offline AI processor, enhancing the information delivery experience.

3D Model Research

Research and integrate 3D model generative AI to identify optimal methods for adding new content to the virtual environment efficiently.

Scalable Open-Source Solution

Design a scalable, open-source solution that serves as a template for other use cases beyond IBM, such as NHS training environments, with comprehensive documentation to support wider adoption.

Requirement Gathering

User Interviews and Personas

As part of our requirements gathering process, we conducted a series of semi-structured interviews and created detailed user personas to better understand user needs and expectations for the AR experience.

End User

VR/AR Experience Visitor

Goals

Experience virtual tours with engaging, interactive content. Easily navigate and access information.

Challenges

May have varying levels of technical expertise and comfort with VR/AR technology.

Preferences

Prioritizes intuitive navigation, clear information presentation, and immersive experiences.

Persona Sketch
End User Persona Sketch

Interview Responses
How familiar are you with AR or VR technology? Have you used anything similar before?

"Not really. I've seen videos of people using VR for gaming, but I've never tried it myself. I'm curious, though! It looks cool, and I'd like to see how it can help me understand complex topics."

During the workshop, would you prefer more guidance or a chance to explore on your own with some direction?

"A bit of both, I think. I like to start with some guidance, so I know what I'm looking at. But after that, it would be fun to explore on my own. I think I'd learn more if I could go at my own pace and check things out without too much pressure."

What aspects of AR/VR technology are you most excited about or interested in exploring?

"A bit of both, I think. I like to start with some guidance, so I know what I'm looking at. But after that, it would be fun to explore on my own. I think I'd learn more if I could go at my own pace and check things out without too much pressure."

Lastly, what would make this experience memorable and enjoyable for you?

"For me, it's about being able to understand something really complex in a simple way. If I can come away feeling like I 'get' Quantum Computing, even just a little, I'd be happy. Also, if there's a way to share what I've learned, like a summary I can take away, that would be great."

Key Conclusions from User Research

Based on our interviews and persona development, we identified these critical insights about what users value most:

  1. Intuitive Navigation with Flexible Guidance
    Users prioritize an interface that's easy to navigate with optional guidance. They prefer starting with basic orientation then exploring independently at their own pace.
  2. Content Customization and Flexibility
    Administrators need straightforward tools to customize content for different audiences, with the ability to select relevant models and information based on specific visitor groups or events.
  3. Complex Information Made Accessible
    Users value experiences that simplify complex technical concepts through visualization and interaction, with takeaway summaries for later reference.
  4. Professional Presentation with Adaptable Branding
    The solution must support professional-level presentation with adaptable branding options that can be tailored to different clients, partners, or special events.

Use Case Diagrams

Admin User Workflow

Content creation and environment setup process

1. Access Dashboard

Admin logs into the system and accesses the main dashboard

2. Create New Activity

Admin initiates the creation of a new virtual tour activity

4. Create New Scene

Design the virtual environment where the activity will take place

4A. Add 3D Assets
  • Upload custom 3D objects
  • Select from preset asset library
  • Configure VR environment
4B. Configure AI Section
  • Add RAG reference documents
  • Configure "Hey Genie" prompt
  • Set up AI response parameters
5. Launch Project

Generate two executables for different user roles:

Admin Executable
  • Place objects in the VR space
  • Scale and position assets
  • Configure multiplayer room settings
Viewer Executable
  • Multiplayer room access
  • Preconfigured 3D assets display
  • AI UBIQ Genie chatbot integration

Admin User Use Cases

ID Use Case Description
AC1 Access Dashboard Admin logs into the system and accesses the main dashboard where they can view and manage all activities.
AC2 Create New Activity Admin creates a new VR activity by configuring title, image URL, VR mode, and target device IP address settings.
AC3 Create Scene Admin designs the virtual environment where the activity will take place, setting up the base structure.
AC4 Manage 3D Assets Admin uploads custom 3D models or selects from preset library to populate the virtual environment.
AC5 Configure AI Assistant Admin adds reference documents for the RAG-enabled chatbot and configures the "Hey Genie" activation phrase.
AC6 Configure Connection Settings Admin adjusts network settings including target device IP address for connecting with the viewer application.
AC7 Generate Executables Admin launches the project to create both admin and viewer executables for different user roles.
AC8 Place and Scale Objects Admin uses the admin executable to precisely position and scale 3D objects in the preferred locations within the VR environment.

MoSCoW Requirements

Functional Requirements

Priority ID Category Requirement
Must Have F1 Admin Interface Web-based admin dashboard for creating and managing virtual activities
Must Have F2 User Management Organization management system with multiple user accounts
Must Have F3 VR Experience VR viewer application for end users to experience created content
Must Have F4 Content Creation Support for 3D object placement and manipulation in virtual environments
Must Have F5 AI Integration RAG-enabled AI guide that responds to user voice queries
Must Have F6 Content Management Document upload system for creating AI knowledge base
Must Have F7 Collaboration Real-time voice interaction between users in the same virtual space
Should Have F8 Content Creation PC-based scene editor for precise object placement and manipulation
Should Have F9 Security Activity join codes for secure access to virtual environments
Should Have F10 Content Creation Support for multiple file formats for 3D models
Should Have F11 Integration Pairing system between admin dashboard and VR applications
Could Have F12 Content Creation Customizable virtual environment templates
Could Have F13 Analytics User analytics and activity metrics for administrators
Could Have F14 Accessibility Non-VR access for desktop users
Could Have F15 Interaction Hand gesture recognition for non-verbal communication
Won't Have F16 AR Features AR passthrough capabilities (deferred to future version)
Won't Have F17 AI Generation AI-generated 3D models from text or image inputs

Non-Functional Requirements

Priority ID Category Requirement
Must Have NF1 Security Secure authentication and authorization system
Must Have NF2 Usability Responsive design for admin dashboard on mobile and desktop devices
Must Have NF3 Compatibility Support for major VR headsets (Oculus Quest, HTC Vive, Valve Index)
Must Have NF4 Performance Low-latency voice communication (< 200ms delay)
Should Have NF5 Performance Efficient 3D asset loading and optimization
Should Have NF6 Compatibility Cross-browser compatibility for admin dashboard
Should Have NF7 Accessibility User interface accessibility features
Should Have NF8 Reliability Data backup and recovery mechanisms
Could Have NF9 Reliability Offline mode for previously loaded environments
Could Have NF10 Performance Performance optimization for low-end devices
Won't Have NF11 Accessibility Full native mobile application for admin dashboard
